Category

Project

Specifications

INTPUT

DC1, DC 2 , cigarette lighter input

14.6 V /10 A charger input , supports photovoltaic PWM Tracking, photovoltaic maximum input voltage 2 4V , DC5521 and cigarette lighter can not be plugged into different power sources and devices at the same time

AC Input

8- digit AC input interface 180V～250V Rated power 200W

AC OUT 220V

AC output voltage

2 AC sockets AC220V±5%

AC output power

6 00W

AC output over power protection

610W ~ 700W​

AC output waveform

Pure sine wave

AC instantaneous output power

≥ 12 00W

frequency

50Hz

USB output port

TYPE-C output

QC3.0 MAX 12V/1.5A (18W)

PD MAX 12V/ 1.5A (18W )

USB – A 1 output

QC3.0 MAX 12V / 1.5A (18W )

USB – A 2 USB -A3 output

Total output MAX 5 V/ 3 A (15W)

DC12V output

DC1, DC 2 , cigarette lighter output

12V/10A (120W) MAX

Battery Cell

type

4 series lithium iron phosphate

capacity

576 WH

Voltage range

10V ~ 14.6V​

Cycle life

2 000 times

Full voltage

14.6 V ± 0.1 V

The voltage at which the battery is automatically charged

LED display​

Display power, charging, and stop charging status

Voltage and power bar display

DC, AC, LED , inverter status

Display screen shows

Boot static

﹤1W ( without AC)

Protection function

Short circuit, overload, over temperature, over voltage, over current, under voltage, etc.

Ambient temperature

Discharge environment temperature

-20 ℃ ～ 45 ℃

Charging environment temperature

0 ℃ ～ 45 ℃

Over temperature protection

Over temperature protection

≥85℃

Over temperature recovery

≤70℃

Use equipment

Equipment power

Discharge time

cell phone

4000mAh

Can be charged about 32 times

Tungsten filament bulb

40W

About 12 hours

Household fans

75W

About 7 hours

Laptop

35W

About 13.5 hours
